Point Cloud Data & CAD Integration

From Reality into 3D-CAD – Using Point Clouds More Smartly
Digitizing existing plants and buildings today requires precise, complete, and efficient methods of data capture and processing. Laser scanning produces highly accurate point clouds that provide a realistic image of the environment. But only through intelligent post-processing do these data become a reliable foundation for planning, design, and engineering.
This is where UNITEC Informationssysteme GmbH comes in – with solutions that seamlessly integrate point clouds into your CAD and planning processes.
Our Solutions in Detail
- Selective Conversion of Point Cloud Data
Not every piece of information in a point cloud is relevant for planning. Our tools and methods allow you to selectively choose sections and convert them into surface models.
Advantages:- Reduced data volumes for more efficient processing
- Compatibility with common CAD systems (e.g., AutoCAD, Solid Edge, Plant 3D)
- Increased efficiency, since only relevant data are transferred into the design model
- Combining CAD Models with Point Clouds
By overlaying 3D-CAD models with real-world point clouds, a digital overall picture is created that offers invaluable benefits in planning and coordination:- Early error detection – deviations become visible before costs arise
- Target/actual comparison – perfect foundation for client meetings and coordination with planning partners
- Visual transparency – makes communication easier between all project participants
Typical Customer Challenges
Many companies face the following problems when working with point clouds:
- Large data volumes that overload systems
- Manual re-modeling that is time- and cost-intensive
- Media discontinuities when moving from laser scan data to CAD environments
With UNITEC solutions, these obstacles are a thing of the past.
Your Advantages with UNITEC
- More transparency throughout the planning process
- Reduced rework thanks to automated data integration
- Greater planning security for complex plants and construction projects
- Future-proof data basis, also usable for expansions and follow-up systems
- Over 25 years of experience in digitization, CAD integration, and system integration
Why UNITEC?
As a German company with more than 25 years of project experience, we combine deep technical know-how with practical implementation. Our customers benefit from tailor-made solutions, precisely adapted to their requirements – independent of industry or system environment.
With UNITEC Informationssysteme GmbH, you can bring your point cloud data into your planning processes faster, more securely, and more efficiently.
Contact us for a personal consultation and learn how your company can benefit from smarter point cloud integration.
Why UNITEC?
As a German company with more than 25 years of project experience, we combine deep technical know-how with practical implementation. Our customers benefit from tailor-made solutions, precisely adapted to their requirements – independent of industry or system environment.
With UNITEC Informationssysteme GmbH, you can bring your point cloud data into your planning processes faster, more securely, and more efficiently.
Contact us for a personal consultation and learn how your company can benefit from smarter point cloud integration.
